Moser Engineering - M9 Rear End - Complete - 1967-1969 GM F-Body: Camaro & Firebird
Description
Application: 1967-1969 GM F-Body: Camaro & Firebird
If you have questions regarding rear ends and their options read the "Ordering A Rear End - The Master FAQ List" in our Support Center.
The Moser Engineering M9 bolt-in housings for the 1967-1969 GM F-Body Camaro and Firebird are made to not only withstand the demands of high horsepower applications, but also finish off the back half of any show car with style.
The Moser M9 bolt-in rears are made from 1/8" thick CNC laser cut mild steel, which is fabricated from one triangulated piece of metal. Combine that with a 3/8" thick face plate, and standard internal gussets and bulk heads and the M9 bolt-in is ready to take on the toughest racing conditions. Also included are custom machined fill and drain vents and wheel stud kit.
The Moser M9 rear end is a 100% bolt in for your 1967-1969 GM F-Body Camaro
and Firebird. It includes all necessary leaf spring and shock mounts.
Specifications:
- Uses 3.00" x .250" thick DOM axle tubing
- Built to bolt right in
- Powder coating available
- Your choice of housing ends
- Made from 1/8" thick laser cut mild steel
- 1350 Pinion Yoke
The M9 is available with many options, please select the components you wish to have
your rear built with from the drop down option boxes. If you have any questions on the best set up for your application, email our tech department for assistance in making the right choices.
Shipping: The Moser M9 rear ships via UPS Ground.
